JDA Power Inverter

The JDA Power Inverter, a 1.2 kW PWM conversion unit for fixed AC output, meets military standards as a reliable naval backup power supply.

The JDA Power Inverter is a robust, 1.2 kW PWM conversion inverter designed for fixed AC output. Primarily serving the naval sector as a backup shipboard power supply, it meets stringent military standards for reliability and performance in demanding environments.

  • Developed for critical applications within naval environments, the JDA Power Inverter ensures a reliable backup power supply with its 1.2 kW capacity. Adhering to MIL-STD-1399(NAVY) and STANAG 1008, this inverter offers stable, fixed AC output, embodying advanced PWM conversion technology for efficient power conversion and minimal harmonic distortion. Its design focuses on operational reliability and compatibility, making it an indispensable asset for shipboard power systems.

    • DC Input: Compliant with Stanag-1008; 24/28V nominal, 18-35V transient, with spike protection up to 600V.

    • AC Output: 115VAC, 60Hz, single-phase; min. 1250 Watts output, max. 11A rms, ±7% voltage tolerance.

    • Environmental: Operational temperature +5°C to +45°C; non-operating -10°C to +60°C; up to 95% RH humidity; meets MIL-S-901C shock and MIL-STD-167 vibration standards.

    • Reliability: MTBF of 100,000 hrs; compliant with MIL-STD-461B for EMI control.

    • Physical: Weight 26kg; dimensions 412H x 326W x 234D mm; IP23 protection; bulkhead-mounted with MIL-C-5051 connectors.

    • Cooling & Protection: Convection with fan assistance; safeguards against over-temperature, polarity reversal, over-voltage, short-circuit, and overload.
